Anthracite Grey Circular Soffit Vent (70mm)

Our Manthorpe anthracite grey 70mm circular soffit vent can be slotted into the soffit board prior to installation for new build situations or just as easily retrofitted into existing soffits. Standard fixing for this product is a simple push-twist action into a 70mm hole drilled in the soffit board. The vent features evenly spaced slots small enough to prohibit large insects from gaining access but wide enough not to be blocked by debris, paint or water droplets.

‣ To achieve 10,000 mm²/m of free airflow, the G700 should be fitted at 200mm centres.
‣ To achieve 25,000 mm²/m of free airflow, the G700 should be fitted at 86mm staggered centres.
‣ Push fit into 70mm diameter hole in soffit board.
